Actual Measuring Construction AI Robot
A Robot For Indoor Measurement
The robot adopts intelligent measuring head and four-wheel drive omnidirectional chassis technology, and achieves navigation motion and high-precision measurement through innovative 3D stereo vision technology and laser positioning navigation technology. Adopting four-wheel drive omnidirectional chassis technology and intelligent measuring heads, the measuring module of the measuring head can achieve autonomous target recognition, measurement analysis data uploading, report generation and other functions, realizing unmanned autonomous building measurement and report output.
Product Description
High Efficiency: Complete a single measurement item in 15 seconds, synchronize data storage and upload.
High Precision: The point cloud accuracy reaches 0.1 millimeters, which is one order of magnitude higher than the measurement standard.
High Returns: Save over 90% of labor costs.
| Actual Measuring Construction AI Robot | |||
| Maximum Overall Dimensions | 575x470x1220 mm | Overall Weight | 42 kg |
| Recommended Measuring Distance | 1.5 m | Measuring Efficiency | 4 measurement items per minute |
| Rated Power | 1.8 kw | Charging Time | 3 – 3.5 h |
| Working Endurance Time | 9 h | Driving Method | Motor four – wheel omnidirectional drive |
| Probe Storage Dimensions | 720x220x135mm | Chassis Storage Weight | 55 kg |
| Obstacle – crossing Ability | 3 cm | ||
Product Gallery
